1771-OZL 1771 Digital Output Module

Model: 1771OZL
Place of Origin: Fujian,China (Mainland)
Brand Name: ALLEN BRADLEY
SIZE: CM
WARRANTY: ONE YEAR
WEIGHT: KG
COLOUR: DIFFERENT
currency: USD
version: A/B/C/D
voltage: VDC
current: A

inquiry

skype basketAdd to Basket  Edit

Share |

Product Description

Payment & Shipping Terms Supply Capacity
Unit Price:10.0~40.0 USDProduction Capacity:866
Trade Term:FOB,EXWPacking:FACTORY SEAL
Payment Terms:T/TDelivery Date:3days
Min. Order:1 Piece/Pieces
Means of Transport:Ocean, Air, Land

Allen Bradley  1771-OZL  !!!


Contact: Jessica

Moore Automation

Tel / Whatsapp:+8618030235311

Wechat: hu18030235311

E-mail: sales*mvme.cn (please change * to @)




The 1771–OZL module has 8 Form A relays. The outputs are arranged in 4 groups of 2, each group with its own common. Each output is electrically isolated from module logic circuitry. The module can simultaneously switch all 8 outputs to separate loads, each conducting a maximum load of 100mA continuously, at rated power.



The controller or I/O chassis power supply, connected through the backplane of the I/O chassis, powers the logic circuitry of the contact output modules.



This supply also provides the necessary power to energize the coils of the module relays. Each energized relay draws 37mA from this supply. The maximum current drawn from this supply when all coils are energized is 420mA.














Outputs per Module
8 (4 groups of 2)



Module Location
1771 Series A or B I/O chassis



Contact Configuration
8 Form A (N.O.)



Voltage Rating
0-24V AC RMS; 0-24V DC



Current Rating
100mA per output (maximum)



Surge Current
100mA maximum per output (at rated power)



Isolation Voltage
1000V open contacts; 1500V coil to contacts



Thermal Dissipation
7.6 BTU/hr (max.), 6.9 BTU/hr (min.)











Allen Bradley  1771-OZL


AB  1771OZL





1)100% full New! - Original Factory Seal !
2)Warranty: 12 months!
3)Package: Original packing with cartons.
4)Delivery time: Shipped in 3 days after payment
5)ship to you via DHL/TNT/UPS/EMS/Fedex.
6) All the goods will be tested before shipment.






More products --- please contact us !!!
