1794-IE8 | ALLEN BRADLEY | +/- 10V Input Voltage

Model: 1794IE8
Place of Origin: Fujian,China (Mainland)
Brand Name: ALLEN BRADLEY
Brand Name: ALLEN BRADLEY
Country of origin: USA
WARRANTY: Twelve months
WEIGHT: 1bs
COLOUR: DIFFERENT
currency: USD/EUR/CNY
version: C/D/E/F
current: A/mA/uA
voltage: VDC
SIZE: CM/MM

inquiry

skype basketAdd to Basket  Edit

Share |

Product Description

Payment & Shipping Terms Supply Capacity
Unit Price:666.0~999.0 USDProduction Capacity:666
Trade Term:FOB,EXWPacking:New carton packaging
Payment Terms:T/TDelivery Date:3 days after payment
Min. Order:10 Piece/Pieces
Means of Transport:Ocean, Air, Land

1794-IE8 | ALLEN BRADLEY | +/- 10V Input Voltage


Moore Automation

Sales Manager:Jessica

Email:sales*mvme.cn (please change * to @)

Skype:jessica01235483


The Allen-Bradley 1794-IE8 is a FLEX selectable analog input module. This 24 Volts DC module has 8 single-ended non-isolated inputs and 3 key switch positions. It has a 12-bits unipolar resolution with 11 bits + sign bipolar input resolution. No calibration beyond the factory setting is required for this module. It measures 3.7 x 2.1 x 31.8 inches and can be mounted on a DIN rail or panel mount.


The 1794-IE8 module can be installed on a 1794-TB2, 1794-TB3S, 1794-TB3ST, 1794-TB3T, or a 1794-TB3 terminal base unit. It also comes with a power and status indicator and has an open-style enclosure. This module has a voltage specification of 24 Volts DC nominal, 10.5 to 31.2 Volts DC including the 5% AC ripple, a current specification of 60 mA, a voltage certification of 24 Volts DC, and a current certification of 0 to 10 Volts that is user-configurable.


The input voltage terminal has a specification of +/-10 Volts and a certification of 0 to 20 mA, while the input current terminal has a specification of 4 to 20 mA and certification of 0 to 20 mA. It also has a voltage of 2.56 mV/cnt (unipolar) and 5.13 mV/cnt (bipolar) as well as a current of 5.13 µA/cnt. This module has a maximum voltage overload of 30 Volts continuous and a maximum current overload of 32 mA continuous, but there is only one channel for each.
